SmartLine STD800 – Differential Pressure
Honeywell SmartLine STD800 differential pressure smart transmitters can be used in applications from furnace combustion airflow rate to hydrostatic tank gauging, and can be used with any primary flow element to provide repeatable flow measurement.
Part of the SmartLine® family of products, the STD800 is a high performance differential pressure transmitter featuring piezoresistive sensor technology. By combining differential pressure sensing with on chip static pressure and temperature compensation the STD800 offers high accuracy and stability over a wide range of application pressures and temperatures. The SmartLine family is also fully tested and compliant with Experion® PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.
BEST IN CLASS FEATURES
- Accuracies up to 0.035% of span standard & 0.025% of span optional.
- Stability up to 0.01% of URL per year for 15 years.
- Automatic static pressure & temperature compensation.
- Rangeability up to 400:1.
- Response times as fast as 90ms.
- Multiple local display capabilities.
- External zero, span, & configuration capability.
- Polarity insensitive electrical connections.
- Comprehensive on-board diagnostic capabilities.
- Integral Dual Seal design for highest safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0.
- World class overpressure protection.
- Full compliance to SIL 2/3 requirements.
- Modular design characteristics.
- Available with additional 15-year warranty.
- Supports NAMUR NE-107 Extended Diagnostics (FF).
- Plugged Impulse Line Detection Option.
- Dual/Triple Calibration Option (HART & Fieldbus only).
DATASHEET
Please contact sales@motherwell.net.au with your configuration and our team will be in touch.
